AUO 15.65Inch Laptop Lcd Model B156HANACH 1920X1080P 141PPI 350cd/M2 30PIN 3.3V lcd display
B156HANAC.H (Product Code: AUO61BC) is a 15.6" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: WLED Backlight, With LED Driver, Reverse I/F, Matte, AMD FreeSync , eDP1.4, PSR2, Free-Sync. Based on its features, einklcd recommend that this model be applied to Laptop etc. According to the information stored in einklcd this model mass production on Q4, 2025, Now this model is in production. We inputted this model's specification on Sep 18 2025 for the first time. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of B156HANAC.H. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
- Brand
- AUO
- Model P/N
- B156HANAC.H
- Diagonal Size
- 15.6"
- Panel Type
- a-Si TFT-LCD, LCM
- Resolution
- 1920(RGB)×1080, FHD 141PPI
- Pixel Format
- RGB Vertical Stripe
- Active Area
- 344.16(W)×193.59(H) mm
- Bezel Opening
- -
| Outline Size | 350.66(W)×215.34(H) ×2.75(D) mm | Surface | Antiglare |
| Brightness | 500 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry | Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 100% sRGB | Lamp Type | WLED , 15K hours , With LED Driver |
| Frequency | 60Hz | Touch Screen | Without |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) | Application | |
| Signal Interface | eDP (2 Lanes) , eDP1.4 , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
